Jingyue Z790M Snow Dream D4 Overview

High-performance M-ATX motherboard for Intel 12th/13th Gen CPUs. Features robust 14+1+1 power delivery, DDR4 support up to 4000MHz, and comprehensive connectivity with dual 2.5G LAN and WiFi readiness.

Highlights:

Socket: LGA1700 (Intel 12th/13th Gen)

Memory: 4x DDR4 DIMM (Max 64GB, 4000MHz+)

torage: 3x M.2 (PCIe 4.0), 4x SATA 3.0

Network: Dual 2.5G LAN + WiFi Interface

I/O Ports: USB 3.2, Type-C, HDMI, DP

Power: 14+1+1 Phase Dr.MOS Supply

Jingyue Z690M Snow Dream D4 Motherboard

Engineered for Intel 12th-14th Gen LGA1700 processors, this motherboard delivers stable performance with 14+1+1 Dr.MOS power phases. It supports high-speed DDR4 memory and offers versatile connectivity, including dual Type-C ports, 2.5G LAN, and multiple M.2 slots for seamless gaming and productivity.

Key Features

CPU & Memory: Supports LGA1700 (12th/13th/14th Gen); 4x DDR4 slots (Max 64GB, up to 4000MHz, XMP).

Storage: 3x M.2 NVMe slots (1x 4.0 + 2x 3.0), 1x PCIe 4.0 x16 slot, 4x SATA 3.0.

Power & Network: 14+1+1 Dr.MOS Power Supply; 2.5G LAN; WiFi interface (PCIe/CNVi compatible).

Connectivity: Dual Type-C (front & rear), USB 3.2 & 2.0, HDMI, DP.

RGB & Control: 4x 5V 3-pin ARGB headers (MCU-controlled); BIOS recovery button.

Z790M Snow Dream V1.2

Memory Slots: 4 x DDR4 Dual Channel
CPU Socket: Intel LGA1700
Memory Frequency: 2133-4000MHz
Power Phase: 14+1+1 Phase DRMOS Power Supply
PCIe: 2 x PCIe x16 4.0
ARGB Interface: 4 x ARGB 5V 3-pin MCU
M.2 Interface: 3 x M.2 NVMe 4.0
Dimensions: 24.5 x 24.5cm M-ATX
Chipset: Intel Z790

Z690M Snow Dream D4

Memory Slots: 4 x DDR4 Dual Channel
CPU Socket: Intel LGA1700
Memory Frequency: 2133-4000MHz
Power Phases: 14+1+1 Phase DR MOS Power Supply
PCIe: 2 x PCIe x16 4.0
ARGB Headers: 4 x ARGB 5V 3-pin MCU
M.2 Slots: 3 x M.2 NVMe
Dimensions: 24.5 x 24.5cm M-ATX
Chipset: Intel Z690

Product selling points

(1)Z790M Snow Dream,M-ATX size:24.5cm*24.5cm.
(2)Intel LGA1700:Compatible with LGA1700 socket 12th, 13th, and 14th generation processors.
(3)PCIE M.2 NVME: 3 M.2 NVMe 4.0 interfaces.
(4)DDR4 Memory:Dual channel, frequency 2133MHz to 4000MHz.

Details

(1) 2.5G Ethernet interface: Realtek RTL8T25BG chip;
(2) 14+1+1 phase power supply: DRMOS power supply;
(3) Personalized ARGB design:
Equipped with 4 ARGB 5V 3-pin connectors
MCU control chip
Rich color control
Lighting effects and ambiance design rely on color

Luxurious materials, good power supply, and stability

Using 14+1+1 phase drmos power supply, it provides more power supply stability for overclocking and extends its lifespan!

Argb5v3-pin mcu control chip

Equipped with two 4-pin argb 5v headers and an mcu control chip, offering a wide range of color control options. color is key to creating captivating lighting effects and immersive atmospheres

PCIE M.2 NVME 4.0

The motherboard provides three m.2 hard disk interfaces and supports nvme protocol hard disks.

DDR4&PCIE slot

Equipped with 4 ddr4 memory slots for dual-channel, enhanced interface, and more stable and pure signal

Equipped with 2 pclex16 alloy armor graphics card slots.

High-speed interconnected 2.5g ethernet port

Provide the rtl8125bg ethernet chip, which is faster and more stable.

Independently developed luxury materials

Full-coverage cooling armor, high-quality materials, and durability. 14+1+1 phase drmos power supply helps players build a stable and cost-effective motherboard!

Schematic diagram of reasonable layout of motherboard interface

Z790m Snow Dream V1.2 parameters

Processor Type: Supports Intel 12th, 13th, and 14th generation LGA1700 platform processors
Chipset: Intel Z790
Memory Slots: 4 x DDR4 dual-channel
Memory Standard: Dual-channel DDR4 4000/3200/3000/2933/2800/2666/2400/2133MHz frequency
Maximum Memory Capacity: 96GB
SATA Interfaces: 4 x SATA 3.0
M.2 Interfaces: 3 x M.2 NVMe protocol 4.0 interfaces, supporting up to PCIe 4.0 x4 speed
Network Type: RTL8125BG Ethernet chip
Audio Chip: Realtek ALC897 chip
USB Interfaces: 2 x rear USB 3.2 ports, 3 x rear USB 2.0 ports, 1 x front USB 3.2 header, 1 x front USB 2.0 header
Display Interfaces: 1 x HDMI port, 1 x DP port
Power Connectors: 24-pin + 8-pin + 4-pin
Fan Headers: 4 x 4-pin headers, 1 x 3-pin header
Power Phase Design: T4+T+1 phase DRMOS power supply
Type-C Interfaces: 1 x rear Type-C port; 1 x front Type-C header
Graphics Card Slots: 1 x PCI Express x16 4.0 slot; 1 x PCI Express x16 4.0 slot (x4 speed)
ARGB Headers: 4 x ARGB 5V 3-pin (MCU control chip)
Other Interfaces: 1 x one-key BIOS reset button; 1 x SPK buzzer header; DEBUG diagnostic LED; 1 x TPM 2.0 header
Wireless Interface: 1 x WiFi interface compatible with PCIe and CNVI protocol modules
Form Factor: 24.5 x 24.5 cm; M-ATX
